LED DJ BoothYL-LDJB
A curved, movable standing LED DJ booth that transforms any stage into a visual spectacle. Built-in high-resolution GOB LED panels sync with the music to deliver immersive light and content experiences for nightclubs, festivals, weddings, and private events.
GOB Protection, Silky-Smooth Visuals
GOB technology gives the LED surface enhanced protection and higher reliability, while the ≥3840Hz refresh rate delivers silky-smooth motion with no flicker. Fast-moving content stays clear, vivid, and free of ghosting from the first beat to the last.
- GOB technology — enhanced protection, higher reliability
- ≥3840Hz ultra-high refresh rate — silky-smooth motion, no flicker
- High definition — vivid colors and crystal-clear visuals
- Clearer and smoother playback with no ghosting, compared with ≤960Hz displays
Bends to Fit, Stays Perfectly Flat
The YL-LDJB is built on flexible P2.5mm LED modules that can be bent to different degrees, wrapping the screen smoothly around the curved booth frame. Magnetic suction installation lets you fine-tune the surface for flatness, and the flat cable design keeps installation simple.
- Super high definition — P2.5mm pixel pitch
- Good flexibility — the flexible structure can be bent to different degrees
- Magnetic suction installation — magnet adjustment ensures flatness
- Flat cable — convenient installation, helps prevent row needle damage during transport
- IP40 protection rating
Update Content From Anywhere
Operate the DJ booth seamlessly from a computer, smartphone, or iPad. With support for USB, SD card, Wi-Fi, and 4G, content updates are quick and hassle-free — no technician required on-site.
- Remote control via computer, phone, or iPad
- USB and SD card content updates
- Wi-Fi and 4G connectivity
- APP / PC / Cloud Service control
Built for Every Event
From intimate club nights to large-scale festival stages, the YL-LDJB delivers professional-grade visual impact wherever the music takes you.
Pool & Summer Parties
Custom visuals for daytime events
Festivals & Concerts
High-impact stage presence
Birthdays & Private Events
Personalized messages on screen
Nightclubs & Bars
Immersive club visuals
YL-LDJB Full Specifications
| Category | Specification |
|---|---|
| SKU | LDJB |
| Pixel Pitch | P2.5 |
| LED Configuration | A4L 2+16GB |
| Module Resolution | 128(W) × 64(H) dots |
| Screen Resolution | 1024(W) × 384(H) dots |
| Operating Voltage | 4.2–5VDC |
| Power Consumption | 2400W |
| Module Thickness | 16.4mm |
| Driving Method | Constant Current |
| Interface Type | HUB320 |
| Refresh Rate | ≥3840Hz (High Refresh) |
| Brightness | 500 nits |
| Control Method | APP / PC / Cloud Service |
| Module Dimensions | 360 × 160mm |
| Product Size | 1602 × 560 × 1142.5mm |
| Display Screen Size | 2560 × 960mm |
| IP Rating | IP40 |
| Place of Origin | Shenzhen |
| Warranty | 5 Years |
Download the Full Spec Sheet
Complete technical specifications for the YL-LDJB LED Curved DJ Booth — panel dimensions, electrical parameters, LED specs, and setup guide.
FAQ
Ready to Light Up the Stage?
Contact YINGLUX for a personalized quote, custom configuration, or to discuss your event requirements. Our team responds within 24 hours.
